Shanghai Guangzhi’s Valve Bag Packer achieves ±0.5% filling accuracy for 25-50kg cement/gypsum/mortar at 12 bags/min. CE/ATEX-compliant with auto-sealing & robotic handling.
Shanghai Guangzhi Automation's Valve Bag Cement Packaging Unit revolutionizes high-volume packing of cement, gypsum, and dry mortar into 25-50kg valve bags. Integrating hermetic filling (±0.5% accuracy), ATEX-grade dust suppression, and robotic bag handling, it delivers 10-12 bags/minute while eliminating 99.8% of airborne particulates.
1. Hermetic Valve Bag Filling
Zero-Dust Technologye777乐彩线路检测: Sealed filling head with inflatable collar creates airtight connection to bag valve.
±0.5% Gravimetric Accuracye777乐彩线路检测: Triple-load-cell system with anti-segregation vibration for uniform powder density.
2. Smart Automation
Robotic Bag Placement: 6-axis robot picks/positions bags; OCR verifies pre-printed valve alignment (±1mm tolerance).
Auto-Pilot Injection™: Compressed-air injection system fills 50kg bags in 3.5 seconds.
3. Industrial-Grade Resilience
Abrasion-Resistant Construction:
e777乐彩线路检测Hardox 500 wear plates at filling nozzles (3x longer lifespan)
e777乐彩线路检测Tungsten-carbide coating for screw conveyors
IP66 Protection: Full dust/water resistance for harsh plant environments.
4. Production Intelligence
IoT Data Logginge777乐彩线路检测: Real-time OEE tracking via Modbus TCP; cloud-based production reports.
Self-Diagnosis HMI: 10" touchscreen with fault prediction algorithms.
| Parameter | Specification |
|---|---|
| Bag Weight Range | 25-50kg (adjustable) |
| Max Throughput | 12 bags/minute |
| Filling Accuracy | ±0.5% |
| Material Viscosity | Up to 15,000 cP (mortar additives) |
| Dust Emission | ≤1mg/m³ (ISO 21501-4 compliant) |
| Valve Compatibility | Spout types: 35-75mm Ø |
| Power | 380V/50Hz, 18kW |
| Air Consumption | 150 L/min @ 0.7MPa |
| Footprint (L×W×H) | 4500×2800×3800mm |
| Material | Filling Solution | Dust Control |
|---|---|---|
| Cement | Anti-segregation vibration table | Vortex air curtain + pulse-jet filter |
| Gypsum | Pre-breaker hopper (anti-caking) | Negative-pressure suction hood |
| Mortar | High-torque ribbon mixer inline | Bag-shaking dust recovery |
Case Study: UAE Cement Plant
Challenge: 6.8% material loss + manual bag handling bottleneck
Solutione777乐彩线路检测: Integrated valve bag line with robotic palletizing
Results:
99.2% material utilization
Zero manual handling injuries
ROI in 11 months
Global Compliance: CE, ATEX Directive 2014/34/EU, ISO 50001
Critical Upgrades:
| Option | Technical Benefit |
|---|---|
| Explosion-Proof Kit | Zone 21 compliance for combustible dusts |
| Bag-on-Conveyor System | 1500 bags/hour continuous output |
| Moisture Analyzer Probe | ±0.3% real-time moisture control |
Support:
e777乐彩线路检测24/7 remote diagnostics with AR guidance
Critical spare parts (filling heads/sensors) global dispatch ≤72h
APPLICABLE BARREL TYPE
